IronMax Storage Solutions Co., Ltd. is a specialized manufacturer of heavy-duty pallet racking, automated radio shuttle systems, cantilever racks, mezzanine structural platforms, and industrial pallets. Operating from our integrated manufacturing base in Shandong, China, we engineer and deliver fully customizable storage solutions tailored to global distribution centers, cold storage, industrial manufacturing, and retail logistics.
Every racking system in our portfolio is fabricated using structural Q235B and Q355B cold-rolled steel, engineered in strict accordance with international safety standards (FEM 10.2.02, RMI, and ISO 9001). Browse our standard product series below or consult our structural engineering team for bespoke layout designs and structural calculations.
Select by structural type, SKU density, handling equipment, and load requirements. Custom colors, powder coating, and hot-dip galvanized finishes available for all series.
Heavy-duty selective pallet racks engineered for direct 100% access to every pallet SKU. Compatible with standard counterbalanced and reach trucks.
Adjustable boltless longspan metal shelving designed for hand-picked items, small carton storage, and medium-to-heavy industrial parts management.
Heavy-duty steel retail display shelving and gondola units featuring reinforced backboards, modular accessories, and high aesthetic finish.
Specialized structural rack for long, bulky, or irregular materials including steel pipes, timber, aluminium profiles, and heavy plastic tubes.
High-density LIFO pallet storage system using nested cart mechanisms on inclined rails. Maximizes storage density while maintaining row selectivity.
Ideal for high-density storage of homogeneous goods with low SKU counts. Allows forklifts to enter racking lanes directly to load and retrieve pallets.
Semi-automated high-density storage solution utilizing self-powered radio shuttle carts to carry pallets inside channels via remote control instruction.
Maximizes vertical height and floor space by narrowing aisle widths to 1.5m–1.8m. Requires specialized VNA turret trucks or guided rail systems.
Multi-tier rack-supported mezzanine floors that multiply vertical warehouse surface area for order picking, e-commerce storage, and assembly areas.
Heavy-duty clear-span structural steel platforms providing open working floors above ground level without obstructive racking columns below.
Virgin high-density polyethylene plastic pallets engineered for rackable strength, hygienic food/pharma handling, and export logistics.
Ultra-durable, fireproof steel pallets designed for heavy payload handling, cold room endurance, and high-frequency automated conveying systems.
Lightweight, non-corrosive, cleanroom-grade 6061-T6 aluminum alloy pallets ideal for pharmaceutical, chemical, and clean-tech applications.
Stackable and foldable steel pallet boxes engineered for industrial parts turnover, auto-parts logistics, and secure returnable transport.
Heavy-gauge welded steel wire mesh containers featuring drop-gate access for easy part retrieval during manufacturing turnover.
Compare performance indicators across key racking structures to determine the optimal solution for your inventory profile and handling equipment.
| Racking Type | Storage Density | Pallet Selectivity | Stock Rotation (Flow) | Typical Forklift Required | Primary Industrial Use |
|---|---|---|---|---|---|
| Selective Pallet Racking | Standard | 100% Direct | FIFO / LIFO | Standard Counterbalance / Reach | General distribution centers, high SKU variety |
| Very Narrow Aisle (VNA) | High | 100% Direct | FIFO / LIFO | VNA Turret Truck / Guided Reach | High-bay warehouses with restricted footprint |
| Drive-In Racking | Very High | Low (By Lane) | LIFO Flow | Standard Reach / Counterbalance | Cold storage, beverage, seasonal bulk inventory |
| Push Back Racking | High | Medium (By Row) | LIFO Flow | Standard Counterbalance | Medium SKU volume, 2-6 pallets per SKU batch |
| Radio Shuttle Racking | Maximum | Channel Selective | FIFO or LIFO Switchable | Forklift + Automated Shuttle Cart | Food processing, deep-freeze stores, high-throughput |
| Cantilever Racking | Medium | 100% Arm Direct | Any Batch Flow | Side Loader / Standard Forklift | Pipes, timber, metal sheets, linear profiles |
| Rack Mezzanine Platform | Multiplies Floor | 100% Manual Pick | Manual / Conveyor | Hand Pallet Jack / Order Picker | E-commerce fulfillment, spare parts, sorting floors |
How IronMax Storage Solutions Co., Ltd. ensures structural integrity, structural safety, and seamless export delivery for international clients.
We source prime cold-rolled steel (Q235B & Q355B structural grades) with mill test certificates verifying tensile yield strength and metallurgical compliance.
Continuous automated roll-forming lines ensure tight dimensional tolerances on upright column profiles, teardrop beams, and structural box sections.
12-stage pre-treatment wash followed by thermosetting epoxy-polyester powder coating guarantees superior adhesion, scratch resistance, and salt-spray durability.
Beams and uprights are bundled with steel strapping, corner protectors, and moisture-proof plastic wrapping to prevent freight damage during ocean container transit.
Planning a new warehouse layout or expanding storage capacity? Contact the engineering desk at IronMax Storage Solutions Co., Ltd. Send your CAD drawings, pallet dimensions, clear building height, and forklift specifications for a detailed layout proposal and itemized cost breakdown.
